Quick Details

  • Application: Laser Cutting, Industry, etc
  • Condition: New
  • Laser Type: Fiber Laser, Fiber Laser
  • Applicable Material: Metal
  • Cutting Thickness: 0-15mm
  • Cutting Area: 3000*1500mm
  • Cutting Speed: 0-20m/min
  • CNC or Not: Yes
  • Cooling Mode: Air Cooling
  • Control Software: Hasary Laser Software
  • Graphic Format Supported: AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
  • Place of Origin: Hubei, China (Mainland)
  • Brand Name: Hasary Laser
  • Model Number: HLF-1000-3015
  • Certification: CCC, CE, GS, ISO, SGS, FDA, CE , ISO,FDA,CCC
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Key words: fiber laser cutting machine
  • Function: Metal Cutting
  • Laser Power: 500w 800w 1000w 1500w 2000w
  • Color: As Your Order
  • Electric Energy: Three-phase Alternating Current
  • Compatible Software: Coreldraw, AutoCAD
  • Sample Test: Available

Packaging & Delivery

Packaging Details fiber laser cutting machine is packed well in Export Standard Wooden Case.
Delivery Time Shipped in 18 days after payment

High precision Automatic CNC 500w carbon fiber laser cutting machine for metal

Product Overviews

Fiber Laser Cutting Machine Features:

    1. High Speed: is twice higher than the same power Co2 laser cutting machine.

    2. Stable Performance: with world's top import fiber lasers, key parts life up to 100,000 hours fiber transmission.

    3. High Efficiency: is 3 times higher than Co2 laser cutting machine in the efficiency. The cutting speed, low operating costs will return on your investment in double.

    4. Low Cost: the whole power consumption is only 20-30% of similar Co2 laser cutting machine.

    5. Low Gas Consumption: laser-produced without the occurrence of gas; unique air cutting stainless steel sheet technology, no N2 consumption.

    6. Low Energy Consumption: is 20-30% of Co2 laser cutting machine. Energy saving and environmental protection.

    7. Low Maintenance Cost: No laser gas; optical fiber transmission, without lens reflex; without adjusting the optical path.



Fiber Laser Cutting Machine Specifications:

Model

HLF-1000-3015

HLF-1000-2513

HLF-1000-0505

Working Size

3000mm×1500mm

2500mm×1300mm

500×500mm

Worktable Max. Load

1000Kg

800Kg

500Kg

Machine Weight

10000Kg

9000Kg

5000Kg

X-axis Running Distance

1525mm

1320mm

520mm

Y-axis Running Distance

3050mm

2535mm

520mm

Z-axis Running Distance

120mm

120mm

120mm

Laser Power

500W/800W/1KW/2KW

X/Y-axis Positioning Accuracy

±0.03mm/m

X/Y-axis Repeat Positioning Accuracy

±0.02mm

X/Y-axis Max. Acceleration

1.2G

X/Y-axis Max. Positioning Speed

140m/min

Electrical Source

220V±10%/60HZ/60A; 380V±10%/50HZ/100A

CNC System

PA8000

Cooling System

Water Cooling









 Fiber Laser Cutting Machine Application Area:

    Fiber laser cutting machine was used in sheet metal processing, aviation, aerospace, electronic, appliances, subway parts, automobile, machinery, precision parts, ships, metallurgical equipment, elevators, appliances, gifts, tools, processing, decoration, advertising and other external processing metal manufacturing and processing industries.



Fiber Laser Cutting Machine Applicable Materials:

    Fiber laser cutting machine was mainly used for cutting carbon steel, silicon steel, stainless steel, fast cutting aluminum, titanium, galvanized sheet, pickling plate, galvanized plate, copper, gold, silver and other metal materials.

Packaging



All our machines are well packed and transport by export standard wooden case.

We will take photos before shipping to let you know the processing of packing and loading.

Company Information



    Wuhan Hasary Equipment Co., Ltd is a new and high technology enterprise in the Optics Valley of China. Our company is specialized in computer software development and technology transfer, laser equipment, optical-electronic equipment and electromechanical equipment, and we also do the agent of various commodities and technology import and export business.Undertake precise laser processing business.

    Relying on the Chinas optical valley and the advantage of optoelectronic high-tech strength from universities and research institutions, we are the main business agent of the optical equipment such as: metal laser marking machine, laser engraving machine, laser metal cutting machine, laser welding machine, laser die board making machine and others. Our products can be applied to the fields of hardware auto parts, clothing, leathers, toys, electronic appliance, models, process advertising, stones, decorations, plastics, glass industry and others.

    Hasary insists on "quality wins the market and the quality service wins the customers". Complying with European CE certification, our products sell well in over 30 countries and regions, such as Brazil, Mexico, Belgium, Iran, Thailand, Korea, Vietnam, the USA, Germany, Italy, Australia, Pakistan, Egypt, Spain, South Africa and Lithuania, etc.

1.Guarantee for one year,maintenance free of charge for one year.

2.24 hours online service, free technical support.

3.User-friendly English manual and video for machine using and maintaining.

4. Five years engineering service.

FAQ

Q: I don't know what kind of machine i should choose?

    Very easy to choose. Just tell us what you want to do by using CNC laser machine, then let us give you perfect solutions and suggestions.

Q: When I got this machine, but I don’t know how to use it. What should I do?

    We will send video and English manual with the machine. If you still have some doubts, we can talk by telephone or skype and e-mail.

Q:If the machine can’t work well, What should I do?

    1. CD vedio and manual will be offered along with machine, allowing you to operate the machine easily.

    2. Our Machine have one year warranty.So any doubts, just let us know, we will give you solutions.

Q: Why choose Hasary Laser? What's your competitive advantage?

    1. Safe and Good Quality: Alibaba gold supplier and CE,FDA certificate, strict quality control system.
    2. Prompt Delivery: Assembling time 7-15 day; Shipping time: 30-45 day.
    3. Competitive Price: Hasary Laser is a factory, not a trade company.
    4. OEM/ODM: Customer's Designs and logos are welcome, we customize the machine according to your need.
    5. Strength Company: Take part in the exhibition of the world.



Q: Before sending me an inquiry on our machine, pls let me know the following information
    1)
Your materials.  Metal/Acrylic/plywood/MDF?

    2)Your metal or non-metal material size.

    Because in our factory, we have different models according to working area.

    3)You want to engrave or cut?

    If cut, could you tell me your cutting thickness? Because different cutting thickness need different laser tube power and laser power supplier.

    Any need of further information,please feel free to contact us!
